Rapido - Day surgery operating table
№ - 100001860
Merivaara Corp.
Rapido is an all-in-one hydraulic day surgery table for preinduction, transport, operation and recovery. Its variety of features makes it the ideal solution for busy day surgery needs. Rapido enables expedient operating room transfers in the day surgery ward which leads to more efficient use of operating room time crucial in efficient outpatient surgery.
- Dedicated Day-Surgery table
- Cost effective: 1 product, several applications: bed, trolley, operating table, examination table
- Easy to service
- Easy to clean and to operate
- Exceptionally low minimum height
- Base frame of epoxy coated steel
- Casings of chock-resistant ABS-plastics
- Swiveling antistatic twin-castors Æ 150
- Central locking pedal on each castor (locks all castors simultaneously)
- Robust and stable column system
- Table top of 4-5 sections (Head section included)
- Top plates are X-ray translucent high pressure laminate
- X-ray cassette rails along the full length
- Soft antistatic, 70 mm separate mattress set fixed to the table with velcro fitting
- Swing-down side rails
| itle | Basic | Eye-ENT | Upper Body |
| Width | 654 mm | 654 mm | 654 mm |
| Width (table top) | 654 mm | 654 mm | |
| Width (base) | 693 mm | 693 mm | |
| Mattress base (width) | 600 mm | 600 mm | |
| Height adjustment min - max | 650 - 1020 mm | 650 - 1020 mm | 650 - 1020 mm |
| Length | 2050 mm | 1760-2040 mm | 2154 mm |
| Weight | 125 kg | 125 kg | 125 kg |
| Safe working load (SWL) | 160 kg | 160 kg | 160 kg |
| Trendelenburg | -25 ° | -25 ° | -25 ° |
| Reverse Trendelenburg | +18 ° | +18 ° | +18 ° |
| Back section adjustment | -4 - +70 ° | -4 - +70 ° | -4 - +70 ° |
| Head rest adjustment | -40 - +25 ° | -40 - +25 ° | -40 - +25 ° |
| Leg section adjustment | -90 - +18 ° | -50 - +40 ° | -90 - +4 ° |
| Castors size | 150 mm | 150 mm | 150 mm |
| Castor type (antistatic, locking) | antistatic | antistatic | antistatic |
| Mattress base (sections) | 5 (divided foot section) pcs | 4 pcs | 5 (divided foot section) pcs |
