Labomed Prima CS Colsposcope
Labomed - USA
Prima CS colposcopes
CMO 300 mm and H-base
Delivering efficiency, performance and convenience to today’s OBGYN. The Prima CS is a versatile solution for surgical and diagnostic work in gynecology. A meticulously designed optical system and built-in high power LED illumination module come together to provide a more streamlined microscope. A suspension and swivel arm mounted on a stable base brings greater flexibility to both clinical and surgical environments.
A single 27-watt LED intelligently drives the illumination system to deliver over 75,000 Lux at a carefully selected color temperature of 5700K, making Prima CS’s eye-pleasing illumination the brightest in its class. Built into the magnichanger, the LED design makes the system more compact and runs cool for over 50,000 hours.
An Apochromatic 5-step Galilean optical system produces aberration-free images corrected for all primary wavelengths. Proprietary MaxLite™ coatings promise the highest degree of anti-reflective and scratch resistant properties, illuminating images evenly and without artifacts. Fine focusing control is provided through a range of long working distance CMOs. To address digital documentation needs, a host of digital SLR, video camera and CCD adapters are available with the ProLine™.
MICROSCOPE SPECIFICATIONS
Prima CS microscope with an intelligent LED illumination system
Binocular tube options:90º head, 45º head or Ergo head > moving over 210º
Eyepiece: WF 10X/18mm with foldable eye guards, diopter adjustment ± 5mm
Optional: WF 12.5X/18mm
Apochromatic magnichanger: 5 step > 0.4X, 0.6X, 1.0X, 1.6X and 2.5X
Objective: f-300mm, manual focus or oprional vario objective Nu Var
Illumination: 27W LED, 75,000 Lux
Built-in-Filters: Green
Vertical movement of arm: ± 250 mm
Power supply: 100-240V, 50/60HZ, 1.6 Amp
Weight of complete microscope: microscope with carrier (2.8 kg), swivel arm (8 kg) and base with pillar (40 kg)
Optional accessories: beam splitter, CCD and USB cameras
